Volkswagen Golf Mk6 (2008-2012) left front fog lamp/left cornering lamp Wiring diagram
This page shows the only wiring diagram for the component.left front fog lamp/left cornering lamp, which is found in the car Volkswagen Golf Mk6 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front fog lamp/left cornering lamp (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH/ TURN SIGNAL SWITCH/ HEADLAMP DIMMER/ FLASHER SWITCH
FOG LAMP
FUSE 13
FUSE 2
FUSE PANEL C (LEFT SIDE OF DASH)
GRN WIRE
GRY WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEADLAMP DIMMER/ FLASHER SWITCH
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED
INSTRUMENT CLUSTER CONTROL MODULE
LEFT DAY TIME RUNNING LAMP (IF EQUIPPED)
LEFT FRONT FOG LAMP/LEFT CORNERING LAMP
LEFT HEADLIGHT
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LIGHT SWITCH
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
REAR FOG LAMP INDICATOR
RED WIRE
RED/WHT WIRE
RIGHT DAY TIME RUNNING LAMP (IF EQUIPPED)
RIGHT FRONT FOG LAMP/RIGHT CORNERING LAMP
RIGHT HEADLIGHT
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (STEERING COLUMN)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH)
VIO WIRE
W/ FOG LAMPS
WHT WIRE
WHT/BLK WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Headlights circuit, early production without hid headlamps -> LEFT FRONT FOG LAMP/LEFT CORNERING LAMP
