Volkswagen Golf Mk6 (2008-2012) front passenger rear view mirror turn signal lamp Wiring diagram
This page shows the only wiring diagram for the component.front passenger rear view mirror turn signal lamp, which is found in the car Volkswagen Golf Mk6 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger rear view mirror turn signal lamp (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/RED WIRE
EMERGENCY FLASHER SWITCH
FRONT PASSENGER REAR VIEW MIRROR
FRONT PASSENGER REAR VIEW MIRROR TURN SIGNAL LAMP
GRN/RED WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
LEFT BACKUP LAMP/ LEFT REAR FOG LAMP
LEFT HEADLIGHT
LEFT TAIL LAMP
MIRRORS SYSTEM
RED/BLK WIRE
RIGHT BACKUP LAMP/ RIGHT REAR FOG LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLIGHT
RIGHT HID HEADLAMP
RIGHT SIDE MARKER LAMP
RIGHT STATIONARY CORNERING LAMP
RIGHT TAIL LAMP
W/ HID
W/O HID
WHT WIRE
Go to component -> Exterior lamps circuit, early production (2 of 3) -> FRONT PASSENGER REAR VIEW MIRROR TURN SIGNAL LAMP
