Volkswagen Golf Mk6 (2008-2012) external multimedia device interface Wiring diagrams

This page contains all the electrical diagrams for the component. external multimedia device interface, in which he is found in the car Volkswagen Golf Mk6 (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram external multimedia device interface (1 of 3)

Wiring diagram external multimedia device interface for Volkswagen Golf Mk6 (2008-2012) (1 of 3)

Get access

ALL- WHEEL DRIVE CONTROL MODULE AM FREQUENCY FILTER AMPLIFIER BLK WIRE BRN WIRE BRN/WHT WIRE CD CHANGER CELL PHONE OPERATING ELECTRONICS CONTROL MODULE COOLANT FAN CONTROL MODULE ENGINE CONTROL MODULE EXTERNAL MULTIMEDIA DEVICE INTERFACE EXTERNAL MULTIMEDIA DEVICE INTERFACE SHIELD FUEL LEVEL SENSOR, TRANSFER METERING FUEL PUMP PUMP HIGH-MOUNTED BRAKE LAMP BULB IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION IGNITION COIL 1 COIL 2 LEFT REAR FOG LAMP BULB LEFT REAR TURN SIGNAL BULB MAGNETIC FIELD SENSOR FOR COMPASS NCA WIRE POWER STEERING CONTROL MODULE RADIO/ NAVIGATION DISPLAY CONTROL MODULE REAR LID UNLOCK MOTOR REAR WINDOW DEFOGGER REAR WINDOW WIPER MOTOR RIGHT LICENSE PLATE LAMP RIGHT REAR FOG LAMP BULB THROTTLE VALVE CONTROL MODULE W/ POWER OUTPUT STAGE WHT WIRE

Go to component -> Ground distribution circuit, early production (4 of 4) -> EXTERNAL MULTIMEDIA DEVICE INTERFACE

Wiring diagram external multimedia device interface (2 of 3)

Wiring diagram external multimedia device interface for Volkswagen Golf Mk6 (2008-2012) (2 of 3)

Get access

ALL- WHEEL DRIVE CONTROL MODULE AM FREQUENCY FILTER AMPLIFIER AUXILIARY ENGINE COOLANT HEATER RADIO FREQUENCY RECEIVER BLK WIRE BRN WIRE BRN/WHT WIRE CD CHANGER CELL PHONE OPERATING ELECTRONICS CONTROL MODULE EXTERNAL MULTIMEDIA DEVICE INTERFACE EXTERNAL MULTIMEDIA DEVICE INTERFACE SHIELD FUEL LEVEL SENSOR, TRANSFER FUEL PUMP HIGH-MOUNTED BRAKE LAMP BULB IGNITION COIL 1 IGNITION COIL 4 IGNITION COIL 5 IGNITION IGNITION COIL 2 COIL 3 LEFT BRAKE/ TAIL LAMP BULB, LEFT REAR TURN SIGNAL BULB LEFT TAIL LAMP BULB, LEFT REAR FOG LAMP BULB LUGGAGE COMPARTMENT LAMP MAGNETIC FIELD SENSOR FOR COMPASS METERING PUMP POWER STEERING CONTROL MODULE RADIO REAR LID UNLOCK MOTOR REAR WINDOW DEFOGGER REAR WINDOW WIPER MOTOR RIGHT TAIL LAMP BULB, RIGHT REAR FOG LAMP BULB THROTTLE COOLANT VALVE FAN CONTROL CONTROL MODULE MODULE W/ POWER OUTPUT STAGE WHT WIRE

Go to component -> Ground distribution circuit, late production (4 of 4) -> EXTERNAL MULTIMEDIA DEVICE INTERFACE

Wiring diagram external multimedia device interface (3 of 3)

Wiring diagram external multimedia device interface for Volkswagen Golf Mk6 (2008-2012) (3 of 3)

Get access

BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM EXTERNAL AUDIO SOURCE CONNECTOR EXTERNAL MULTIMEDIA DEVICE INTERFACE FUSE FUSE PANEL FUSE PANEL C (LEFT SIDE OF DASH) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RADIO/NAVIGATION DISPLAY CONTROL MODULE RED WIRE RED/WHT WIRE RED/YEL WIRE W/ STOP/START SYSTEM W/O STOP/START SYSTEM WHT WIRE YEL WIRE

Go to component -> Multimedia interface circuit -> EXTERNAL MULTIMEDIA DEVICE INTERFACE
