Volkswagen Golf Mk6 (2008-2012) dc/ac converter switch, electric socket control lamp Wiring diagrams
This page contains all the electrical diagrams for the component. dc/ac converter switch, electric socket control lamp, in which he is found in the car Volkswagen Golf Mk6 (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dc/ac converter switch, electric socket control lamp (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN/RED WIRE
CONVERTER W/ SOCKET,
DC/AC CONVERTER SWITCH, ELECTRIC SOCKET CONTROL LAMP
DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
DRIVER'S SEAT ADJUSTMENT SWITCH
ELECTRONIC DAMPING CONTROL MODULE
FROM FUSE 6 (DIAGRAM 2 OF 6)
FROM FUSE PANEL B (DIAGRAM 2 OF 6)
FRONT SEAT HEATING CONTROL MODULE
FUSE 32
FUSE 33
FUSE 35
FUSE 36
FUSE 37
FUSE PANEL C (LEFT SIDE OF DASH) FUSE 34
GENERATOR
GRN WIRE
GRY WIRE
HEADLAMP WASHER RELAY
IGNITION SWITCH KEY LOCK SOLENOID (W/ DSG TRANSMISSION)
IGNITION/STARTER SWITCH
NCA WIRE
POWER SUNROOF CONTROL MODULE (IF EQUIPPED)
RED WIRE
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, early production (5 of 6) -> DC/AC CONVERTER SWITCH, ELECTRIC SOCKET CONTROL LAMP
Wiring diagram dc/ac converter switch, electric socket control lamp (2 of 2)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN/RED WIRE
CONVERTER W/ SOCKET,
DC/AC CONVERTER SWITCH, ELECTRIC SOCKET CONTROL LAMP
DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
DRIVER'S SEAT ADJUSTMENT SWITCH
ELECTRONIC DAMPING CONTROL MODULE
FROM FUSE 6 (DIAGRAM 2 OF 6)
FROM FUSE PANEL B (DIAGRAM 2 OF 6)
FRONT SEAT HEATING CONTROL MODULE
FUSE 32
FUSE 33
FUSE 35
FUSE 36
FUSE 37
FUSE PANEL C (LEFT SIDE OF DASH) FUSE 34
GENERATOR
GRN WIRE
GRY WIRE
HEADLAMP WASHER RELAY
IGNITION SWITCH KEY LOCK SOLENOID (W/ DSG TRANSMISSION)
IGNITION/STARTER SWITCH
NCA WIRE
POWER SUNROOF CONTROL MODULE (IF EQUIPPED)
RED WIRE
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, late production (5 of 6) -> DC/AC CONVERTER SWITCH, ELECTRIC SOCKET CONTROL LAMP
