Volkswagen Golf Mk6 (2008-2012) cruise control switch, cruise control set-button Wiring diagram
This page shows the only wiring diagram for the component.cruise control switch, cruise control set-button, which is found in the car Volkswagen Golf Mk6 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control switch, cruise control set-button (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SET BUTTON (IF EQUIPPED)
CRUISE CONTROL SWITCH (IF EQUIPPED)
CRUISE CONTROL SWITCH, CRUISE CONTROL SET-BUTTON
ENGINE CONTROLS SYSTEM
GRN WIRE
GRY WIRE
HORNS SYSTEM
MULTI- FUNCTION SWITCH
MULTI-FUNCTION INDICATOR MEMORY SWITCH (W/ MULTI-FUNCTION DISPLAY)
MULTI-FUNCTION INDICATOR SELECTION SWITCH (W/ MULTI-FUNCTION DISPLAY)
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
REAR WINDOW WIPER SWITCH, WINDSHIELD, HEADLAMP WASHER PUMP SWITCH
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/YEL WIRE
SHIFT INTERLOCK SYSTEM
SHIFT INTERLOCK, TRANSMISSIONS SYSTEMS
STARTING/CHARGING SYSTEM
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (STEERING COLUMN)
SUPPLEMENTAL RESTRAINTS SYSTEM
TURN SIGNAL SWITCH, HEADLIGHT DIMMER/ FLASHER SWITCH
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH)
VIO WIRE
W/ MULTIFUCTION
W/O MULTIFUCTION
WINDSHIELD WIPER INTERMITTENT MODE SWITCH
WINDSHIELD WIPER INTERMITTENT REGULATOR
YEL WIRE
Go to component -> Steering column electronic systems control module circuit, late production (1 of 2) -> CRUISE CONTROL SWITCH, CRUISE CONTROL SET-BUTTON
