Volkswagen Golf Mk6 (2008-2012) air bag malfunction indicator lamp Wiring diagrams
This page contains all the electrical diagrams for the component. air bag malfunction indicator lamp, in which he is found in the car Volkswagen Golf Mk6 (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram air bag malfunction indicator lamp (1 of 2)
AIR BAG CONTROL MODULE (FRONT OF CENTER CONSOLE)
AIR BAG MALFUNCTION INDICATOR LAMP
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE REAR AIR BAG CRASH SENSOR (LEFT TRIM PANEL)
DRIVER'S FRONT AIR BAG CRASH SENSOR (LEFT SIDE OF RADIATOR SUPPORT)
DRIVER'S SIDE AIR BAG CRASH SENSOR (DRIVER DOOR)
DRIVER'S SIDE REAR SAFETY BELT TENSIONER IGNITER (IF EQUIPPED)
FRONT PASSENGER'S FRONT AIR BAG CRASH SENSOR (RIGHT SIDE OF RADIATOR SUPPORT)
FRONT PASSENGER'S SAFETY BELT TENSIONER IGNITER 1 (IF EQUIPPED)
FRONT PASSENGER'S SIDE AIR BAG CRASH SENSOR (FRONT PASSENGER'S DOOR)
FRONT PASSENGER'S SIDE REAR SAFETY BELT TENSIONER IGNITER (IF EQUIPPED)
GRN WIRE
GRY WIRE
GRY/RED WIRE
INSTRUMENT CLUSTER CONTROL MODULE W/ DISPLAY UNIT
ORG/BLK WIRE
ORG/BRN WIRE
PASSENGER'S REAR SIDE AIR BAG CRASH SENSOR (RIGHT TRIM PANEL)
RED WIRE
SAFETY BELT WARNING LAMP
SOLID STATE
VIO WIRE
WARNING BUZZER
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Supplemental restraints circuit, early production with rear side air bag (3 of 3) -> AIR BAG MALFUNCTION INDICATOR LAMP
Wiring diagram air bag malfunction indicator lamp (2 of 2)
AIR BAG CONTROL MODULE (FRONT OF CENTER CONSOLE)
AIR BAG MALFUNCTION INDICATOR LAMP
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE REAR AIR BAG CRASH SENSOR (LEFT TRIM PANEL)
DRIVER'S FRONT AIR BAG CRASH SENSOR (LEFT SIDE OF RADIATOR SUPPORT)
DRIVER'S SIDE AIR BAG CRASH SENSOR (DRIVER DOOR)
DRIVER'S SIDE REAR SAFETY BELT TENSIONER IGNITER (IF EQUIPPED)
FRONT PASSENGER'S FRONT AIR BAG CRASH SENSOR (RIGHT SIDE OF RADIATOR SUPPORT)
FRONT PASSENGER'S SAFETY BELT TENSIONER IGNITER 1 (IF EQUIPPED)
FRONT PASSENGER'S SIDE AIR BAG CRASH SENSOR (FRONT PASSENGER'S DOOR)
FRONT PASSENGER'S SIDE REAR SAFETY BELT TENSIONER IGNITER (IF EQUIPPED)
GRN WIRE
GRY WIRE
GRY/RED WIRE
INSTRUMENT CLUSTER CONTROL MODULE W/ DISPLAY UNIT
ORG/BLK WIRE
ORG/BRN WIRE
PASSENGER'S REAR SIDE AIR BAG CRASH SENSOR (RIGHT TRIM PANEL)
RED WIRE
SAFETY BELT WARNING LAMP
SOLID STATE
VIO WIRE
WARNING BUZZER
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Supplemental restraints circuit, late production with rear side air bag (3 of 3) -> AIR BAG MALFUNCTION INDICATOR LAMP
