Exterior lamps circuit for Volkswagen Golf Mk3 (1991-2000)

BACK- UP LIGHT BACK-UP LIGHTS CIRCUIT BATTERY BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BRAKE LIGHT BRAKE LIGHT SWITCH (ON BRAKE PEDAL BRACKET) BRN WIRE BRN/WHT WIRE E/3 E/4 FUSE 20 FUSE 3 FUSE 7 FUSE 8 FUSE/ RELAY PANEL (UNDER LEFT SIDE OF DASH) GRN WIRE GRY WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE HEADLIGHT SWITCH J/4 K/10 K/2 K/3 K/4 K/5 LEFT FRONT PARK/TURN SIGNAL LIGHT LEFT FRONT SIDE MARKER LIGHT LEFT LICENSE PLATE LIGHT LEFT TAILLIGHT BULB HOLDER OFF PARK HEAD P/6 R/2 R/5 R/6 R/7 RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT LICENSE PLATE LIGHT TAIL LIGHTS TURN SIGNAL LIGHT W/4 Y/3

ALARM SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH, ABOVE FUSE/ RELAY PANEL) BACK- UP LIGHT BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/WHT/GRN WIRE BRAKE LIGHT BRN WIRE BRN/WHT WIRE EMERGENCY FLASHER RELAY EMERGENCY FLASHER SWITCH EMERGENCY FLASHER WARNING LIGHT FUSE 17 FUSE/ RELAY PANEL (UNDER LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRY/RED WIRE HEADLIGHT/DIMMER FLASHER/SWITCH HIGH MOUNT BRAKE LIGHT HOT IN ON OR START INSTRUMENT CLUSTER J/8 K/1 K/7 LEFT LEFT TURN SIGNAL OFF RED/YEL WIRE RIGHT RIGHT FRONT PARK/TURN SIGNAL LIGHT RIGHT FRONT SIDE MARKER LIGHT RIGHT TAILLIGHT BULB HOLDER RIGHT TURN SIGNAL TAIL LIGHTS TURN SIGNAL LIGHT TURN SIGNAL SWITCH WHT WIRE WHT/YEL WIRE YEL WIRE
