Volkswagen Golf Mk3 (1991-2000) third speed coolant fan control thermal switch a/c pressure switch Wiring diagram
This page shows the only wiring diagram for the component.third speed coolant fan control thermal switch a/c pressure switch, which is found in the car Volkswagen Golf Mk3 (1991-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram third speed coolant fan control thermal switch a/c pressure switch (1 of 1)
6/30 2/86
A/C SHUTOFF RELAY
ABS CONTROL MODULE
ALARM SYSTEM CONTROL MODULE
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER
COOLANT FAN CONTROL MODULE
COOLANT FAN CONTROL THERMAL SWITCH
D/3
DATA LINK CONN- ECTOR
DATA LINK CONN- ECTOR (EX 1.9L) (1.9L)
DAYTIME RUNNING LIGHTS SWITCH-ON RELAY
DRIVER'S CENTRAL LOCKING SYSTEM DOOR SWITCH (1997) ALARM SYSTEM CONTROL MODULE
DRIVER'S CENTRAL LOCKING SYSTEM DOOR SWITCH (1998-99)
DRIVER'S POWER MIRROR (HEATER) PASSENGER'S POWER MIRROR (HEATER)
FOG LIGHT RELAY
FOG LIGHT SWITCH REAR WINDOW DEFOGGER SWITCH
FREE AIR/ RECIRCULATION FLAP SWITCH
FRESH AIR BLOWER SWITCH
FROM FUSE/ RELAY PANEL (15) (DIAGRAM 2 OF 3)
FROM IGNITION SWITCH (DIAGRAM
FRONT INTERIOR LIGHT
FUEL PUMP RELAY (GASOLINE)
FUSE 10
FUSE 125
FUSE 17
FUSE 18
FUSE 19
FUSE 21
FUSE 22
FUSE 4
FUSE 5
FUSE 52
FUSE 6
FUSE 9
GENERATOR
GLOVE COMPARTMENT LIGHT
GLOW PLUG HEATER (1998)
GRN WIRE
GRY WIRE
HEAD LIGHT SWITCH
HEADLIGHT SWITCH
HEADLIGHT/ DIMMER FLASHER SWITCH FUEL PUMP DOOR LOCK/ UNLOCK SWITCH
HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR 2
INSTRUMENT CLUSTER
J/4 M/2 Q/3 Q/5
J/7 K/6
J/C
L/7 L/5
LEFT DOOR WARNING LIGHT
LEFT MAKE-UP MIRROR LIGHT RIGHT REAR READING LIGHT RIGHT MAKE-UP MIRROR LIGHT
LEFT REAR READING LIGHT
LEFT WASHER NOZZLE HEATER
LOAD REDUCTION RELAY
LUGGAGE COMPARTMENT LIGHT
LUGGAGE COMPARTMENT RELEASE SWITCH
MOTRONIC ENGINE CONTROL MODULE
P/4 P/2
PASSENGER'S CENTRAL LOCKING SYSTEM DOOR SWITCH ALARM SYSTEM INDICATOR LIGHT
POWER SUPPLY RELAY (1.9L)
Q/2
Q/5 TRUNK LID RELEASE SWITCH T/1
R/10
R/5
RADIO
REAR WINDOW WIPER/ WASHER RELAY
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT DOOR WARNING LIGHT
RIGHT WASHER NOZZLE HEATER
S/1
STARTER
TEMP RESIS- TOR
THIRD SPEED COOLANT FAN CONTROL THERMAL SWITCH A/C PRESSURE SWITCH
TO FUSE/ RELAY PANEL (30) (DIAGRAM 3 OF 3)
TO FUSE/ RELAY PANEL (DIAGRAM 3 OF 3) 4/87
TO GLOW PLUG RELAY (DIAGRAM 3 OF 3) (1997)
TO IGNITION SWITCH (DIAGRAM
WASHER/ WIPER INTERMITTENT RELAY
WHT WIRE
WINDSHIELD WIPER MOTOR
Y/3
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> THIRD SPEED COOLANT FAN CONTROL THERMAL SWITCH A/C PRESSURE SWITCH
