Volkswagen Golf Mk3 (1991-2000) diesel direct fuel injection engine control module Wiring diagrams
This page contains all the electrical diagrams for the component. diesel direct fuel injection engine control module, in which he is found in the car Volkswagen Golf Mk3 (1991-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram diesel direct fuel injection engine control module (1 of 2)
2/31
BLK WIRE
BRN WIRE
CABRIO ONLY
CENTRAL LOCKING SYSTEM PUMP, CONTROL MODULE
DIESEL DIRECT FUEL INJECTION ENGINE CONTROL MODULE
DOOR LOCK SWITCH (EX CABRIO)
ENGINE SPEED SENSOR
FROM BATTERY (DIAGRAM 1 OF 4)
FUEL LEVEL SENSOR
GENERATOR
GOLF, CABRIO, GTI
HIGH MOUNT BRAKE LIGHT
LEFT BACK-UP/ BRAKE LIGHT BULB HOLDER RIGHT BACK-UP/ BRAKE LIGHT BULB HOLDER
LEFT FRONT POWER WINDOW CONTROL MODULE
LEFT HEATED MIRROR
LEFT LICENSE PLATE LIGHT
LEFT REAR POWER WINDOW SWITCH
LEFT TAILLIGHT BULB HOLDER
LUGGAGE COMPARTMENT LIGHT SWITCH
LUGGAGE COMPARTMENT RELEASE SOLENOID
MASS AIR FLOW SENSOR
NCA WIRE
NEAR LEFT "B" PILLAR)
NEEDLE LIFT SENSOR SHIELD
POWER MIRROR SWITCH
POWER WINDOW CONSOLE SWITCH ASSEMBLY
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RED WIRE
RIGHT FRONT POWER WINDOW CONTROL MODULE
RIGHT FRONT POWER WINDOW SWITCH
RIGHT HEATED MIRROR
RIGHT LICENSE PLATE LIGHT
RIGHT REAR POWER WINDOW SWITCH
RIGHT TAILLIGHT BULB HOLDER
TG/2
TH/2 TJ/2
TRUNK LID ALARM SWITCH
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 4) -> DIESEL DIRECT FUEL INJECTION ENGINE CONTROL MODULE
Wiring diagram diesel direct fuel injection engine control module (2 of 2)
2.8L 1.9L, 2.0L
BLK WIRE
BLK/GRN WIRE
BLU (OR WHT/ WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT (OR WHT) WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
BRN/WHT WIRE
C/1
C/8
D/8
DAYTIME RUNNING LIGHTS DIODE
DIESEL DIRECT FUEL INJECTION ENGINE CONTROL MODULE
ENGINE COOLANT LEVEL SENSOR (AT REAR OF CYLINDER HEAD)
ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR
F/4
FUEL GAUGE SENDER
FUSE/ RELAY PANEL (UNDER LEFT SIDE OF DASH)
GASOLINE DIESEL
GRN (OR GRN/WHT) WIRE
GRN WIRE
HOT AT ALL TIMES
IGNITION SWITCH
JUNCTION CONNECTOR (BEHIND FUSE/RELAY PANEL)
L/1
L/6
LOCK
M/3 M/6
OIL PRESSURE SWITCH (ON TOP OF OIL FILTER HOUSING)
OUTSIDE AIR TEMPERATURE SENSOR
PARKING BRAKE WARNING LIGHT SWITCH
RED WIRE
RED/WHT (OR WHT) WIRE
RUN WIRE
VIO (OR WHT OR VIO/WHT) WIRE
VIO WIRE
W/1
WHT WIRE
YEL (OR WHT) WIRE
YEL WIRE
YEL/RED (OR WHT) WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> DIESEL DIRECT FUEL INJECTION ENGINE CONTROL MODULE
