Driver"s memory seat circuit for Volkswagen Golf R VIII (2020-2024)

ANGLE ADJUSTMENT BUTTON BACKREST ADJUSTMENT BUTTON BLU WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ADJUSTMENT CONTROL MODULE DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SEAT MEMORY BUTTON DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SIDE MASSAGE FUNCTION BUTTON FUSE PANEL 2 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE HOT AT ALL TIMES LEFT FRONT SEAT ADJUSTMENT CONTROL HEAD LEFT FRONT SEAT COUPLING STATION LUMBAR SUPPORT FORWARD/BACK ADJUSTMENT BUTTON LUMBAR SUPPORT HEIGHT ADJUSTMENT BUTTON MEMORY SEAT POSITION 1 BUTTON MEMORY SEAT POSITION 2 BUTTON ORG/BLK WIRE ORG/BRN WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE SEAT FORWARD/BACK ADJUSTMENT BUTTON SEAT HEIGHT ADJUSTMENT BUTTON VIO WIRE VIO/GRN WIRE VIO/YEL WIRE WHT/BLU WIRE YEL/BLK WIRE

BLU WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT MOTOR DRIVER SEAT ADJUSTMENT CONTROL MODULE DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR DRIVER SEAT FORWARD/BACK ADJUSTMENT SENSOR DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT LUMBAR SUPPORT DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE INSTRUMENT CLUSTER LEFT FRONT SEAT COUPLING STATION LUMBAR SUPPORT FORWARD/ BACK ADJUSTMENT SENSOR LUMBAR SUPPORT HEIGHT ADJUSTMENT SENSOR ORG/BRN WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE VIO WIRE VIO/YEL WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE
