Volkswagen Golf R VIII (2020-2024) tiptronic upshift button on steering wheel Wiring diagrams

ACCESS/START SYSTEM INTERFACE BLK/RED WIRE BLK/VIO WIRE BLU/WHT WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM FUSE 42 FUSE 45 FUSE 5 FUSE PANEL C GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRY WIRE PARKING LOCK ACTUATOR PARKING LOCK BUTTON PARKING LOCK SOLENOID RED/WHT WIRE RED/YEL WIRE RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL SELECTOR LEVER SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE SELECTOR LEVER TRANSMISSION RANGE DISPLAY SELECTOR MECHANISM SHIFT LOCK SOLENOID SIGNAL HORN ACTIVATION START SYSTEM BUTTON STEERING WHEEL HEATING BUTTON TIPTRONIC DOWNSHIFT BUTTON ON STEERING WHEEL TIPTRONIC UPSHIFT BUTTON ON STEERING WHEEL VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/BLU WIRE VIO/WHT WIRE WHT WIRE WHT/GRY WIRE WHT/RED WIRE WHT/YEL WIRE

BLK WIRE BRN WIRE CRUISE CONTROL SET BUTTON CRUISE CONTROL SWITCH GRY WIRE HEATED STEERING WHEEL HEATED STEERING WHEEL SENSOR HORNS SYSTEM LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE RED WIRE RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL STEERING WHEEL HEATING BUTTON STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE TIPTRONIC DOWNSHIFT BUTTON ON STEERING WHEEL TIPTRONIC UPSHIFT BUTTON ON STEERING WHEEL VIO/WHT WIRE W/ MULTI-FUNCTION STEERING WHEEL WHT WIRE YEL WIRE
