Volkswagen Golf R VIII (2020-2024) rear power window lock illumination bulb Wiring diagram
This page shows the only wiring diagram for the component.rear power window lock illumination bulb, which is found in the car Volkswagen Golf R VIII (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear power window lock illumination bulb (1 of 1)
BLU/YEL WIRE
BRN WIRE
CHILD SAFETY LOCK BUTTON
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER POWER WINDOW BUTTON
DRIVER SIDE REAR POWER WINDOW BUTTON
DRIVER SIDE REAR WINDOW REGULATOR MOTOR
DRIVER WINDOW REGULATOR MOTOR
FRONT PASSENGER POWER WINDOW BUTTON
FUSE 26
FUSE 9
FUSE PANEL C
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
LEFT REAR DOOR COUPLING POINT
PASSENGER SIDE REAR POWER WINDOW BUTTON
PUSH BUTTON ILLUMINATION BULB
REAR POWER WINDOW LOCK ILLUMINATION BULB
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
Go to component -> Power windows circuit (1 of 2) -> REAR POWER WINDOW LOCK ILLUMINATION BULB
