Volkswagen Golf R VIII (2020-2024) passenger seat occupant detection sensor Wiring diagrams
This page contains all the electrical diagrams for the component. passenger seat occupant detection sensor, in which he is found in the car Volkswagen Golf R VIII (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger seat occupant detection sensor (1 of 4)
BRN WIRE
BRN/YEL WIRE
COUPLING POINT IN LEFT REAR SEAT
DRIVER SEAT ADJUSTMENT CONTROL MODULE
DRIVER SEAT BACKREST BLOWER FAN
DRIVER SEAT BACKREST COUPLING POINT
DRIVER SEAT COUPLING POINT
DRIVER SEAT CUSHION BLOWER FAN
FRONT PASSENGER SEAT BACKREST BLOWER FAN
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER SEAT CUSHION BLOWER FAN
LEFT FRONT SEAT ADJUSTMENT CONTROL HEAD
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATER
LEFT REAR FOOTWELL LAMP
LEFT REAR SEAT HEATER
PASSENGER SEAT OCCUPANT DETECTION SENSOR
RIGHT FRONT SEAT ADJUSTMENT CONTROL HEAD
RIGHT FRONT SEAT COUPLING STATION
RIGHT FRONT SEAT HEATED BACKREST
RIGHT FRONT SEAT HEATER
RIGHT REAR FOOTWELL LAMP
RIGHT REAR SEAT HEATER
Go to component -> Ground distribution circuit (8 of 8) -> PASSENGER SEAT OCCUPANT DETECTION SENSOR
Wiring diagram passenger seat occupant detection sensor (2 of 4)
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/YEL WIRE
FRONT PASSENGER SEAT COUPLING POINT
GRN/BLK WIRE
GRN/BLU WIRE
GROUND DISTRIBUTION SYSTEM
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR HEATED SEAT TEMPERATURE SENSOR
LEFT REAR SEAT COUPLING POINT
LEFT REAR SEAT HEATER
LEFT REAR SEAT HEATING ELEMENT
PASSENGER SEAT OCCUPANT DETECTION SENSOR
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT SEAT COUPLING STATION
RIGHT FRONT SEAT HEATED BACKREST
RIGHT FRONT SEAT HEATER
RIGHT FRONT SEAT HEATING ELEMENT
RIGHT FRONT SEAT TEMPERATURE SENSOR
RIGHT REAR BACKREST HEATING ELEMENT
RIGHT REAR HEATED SEAT TEMPERATURE SENSOR
RIGHT REAR SEAT HEATER
RIGHT REAR SEAT HEATING ELEMENT
Go to component -> Heated seats circuit (2 of 2) -> PASSENGER SEAT OCCUPANT DETECTION SENSOR
Wiring diagram passenger seat occupant detection sensor (3 of 4)
ADAPTIVE CRUISE CONTROL MODULE
AIR QUALITY SENSOR
ALARM HORN
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
BACKUP LAMP SWITCH
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BOTTOM CENTER COUPLING POINT IN INTERIOR
BOTTOM LEFT COUPLING POINT IN INTERIOR
BRN WIRE
CLUTCH POSITION SENSOR
DIAGNOSTIC CONNECTION
DRIVER ASSISTANCE SYSTEMS FRONT CAMERA
ELECTRIC DRIVE POWER, CONTROL ELECTRONICS
FROM FUSE 39 (DIAGRAM 3 OF 6)
FUSE 40
FUSE 48
FUSE 52
FUSE 58
FUSE 59
FUSE 60
FUSE 61
FUSE 64
FUSE 65
FUSE 66
N/A
PARKING AID CONTROL MODULE
PARKING BRAKE BUTTON
PASSENGER SEAT OCCUPANT DETECTION SENSOR
REAR LID COUPLING POINT
REAR WINDOW WIPER MOTOR
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
REFRIGERANT CIRCUIT PRESSURE SENSOR
RIGHT FRONT SEAT COUPLING STATION
SOCKETS RELAY
STRUCTURE BORNE SOUND CONTROL MODULE
TERMINAL 15 POWER SUPPLY RELAY
TO BOTTOM CENTER COUPLING POINT IN INTERIOR (DIAGRAM 5 OF 6)
TO FUSE PANEL 2 (DIAGRAM 2 OF 6)
TO FUSE PANEL B (DIAGRAM 2 OF 6)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
Go to component -> Power distribution circuit (4 of 6) -> PASSENGER SEAT OCCUPANT DETECTION SENSOR
Wiring diagram passenger seat occupant detection sensor (4 of 4)
AIR BAG SPIRAL SPRING/ RETURN SPRING (W/ SLIP RING)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
DRIVER AIR BAG IGNITER
DRIVER HEAD CURTAIN AIR BAG IGNITER
DRIVER SIDE REAR THORAX AIR BAG IGNITER
FRONT PASSENGER AIR BAG IGNITER 1
FRONT PASSENGER AIR BAG IGNITER 2
FRONT PASSENGER AIR BAG UNIT (ABOVE GLOVE BOX)
FRONT PASSENGER THORAX AIR BAG IGNITER
FUSE 64
FUSE PANEL C
GRN WIRE
GRY WIRE
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
PASSENGER SEAT OCCUPANT DETECTION SENSOR
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT SEAT COUPLING STATION
SEATS SYSTEM
STEERING COLUMN ELECTRONICS CONTROL MODULE
VIO/BLK WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Supplemental restraints circuit (2 of 4) -> PASSENGER SEAT OCCUPANT DETECTION SENSOR
