Volkswagen Golf R VIII (2020-2024) left front door coupling point Wiring diagram
This page shows the only wiring diagram for the component.left front door coupling point, which is found in the car Volkswagen Golf R VIII (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door coupling point (21 of 21)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
DRIVER MIRROR ADJUSTMENT MOTOR
DRIVER MIRROR ADJUSTMENT MOTOR 2
EXTERIOR REAR VIEW MIRROR ADJUSTER
EXTERIOR REAR VIEW MIRROR HEATING SWITCH
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FRONT PASSENGER MIRROR ADJUSTMENT MOTOR
FRONT PASSENGER SIDE MIRROR ADJUSTMENT MOTOR 2
FUSE 26
FUSE 9
FUSE PANEL C
GRY WIRE
GRY/YEL WIRE
HEATER
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
MIRROR ADJUSTING SWITCH
MIRROR ADJUSTMENT SWITCH ILLUMINATION BULB
MIRROR FOLDING SWITCH
MIRROR SELECTOR SWITCH
PUSH BUTTON ILLUMINATION BULB
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
TURN SIGNAL BULB
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> LEFT FRONT DOOR COUPLING POINT
