Volkswagen Golf R VIII (2020-2024) instrument panel, switch illumination dimmer switch Wiring diagram
This page shows the only wiring diagram for the component.instrument panel, switch illumination dimmer switch, which is found in the car Volkswagen Golf R VIII (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instrument panel, switch illumination dimmer switch (1 of 1)
BLK/VIO WIRE
BOTTOM CENTER COUPLING POINT IN INTERIOR
BRN WIRE
BRN/YEL WIRE
CENTER INSTRUMENT PANEL SWITCH MODULE
COMPUTER DATA LINES SYSTEM
COUPLING POINT ON ROOF
DRIVER SIDE REAR POWER WINDOW BUTTON
FUSE 35
FUSE 44
FUSE PANEL C
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ILLUMINATION CONTROL HEAD
INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH
LEFT REAR DOOR COUPLING POINT
LEFT REAR EXTERIOR DOOR HANDLE
LEFT REAR EXTERIOR DOOR HANDLE COUPLING POINT
LEFT REAR EXTERIOR DOOR HANDLE ILLUMINATION BULB
LEFT REAR WINDOW REGULATOR MOTOR
LIGHT SWITCH
ORG/BRN WIRE
PARKING BRAKE BUTTON
PUSH BUTTON ILLUMINATION BULB
REAR INTERIOR LAMP
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT FRONT DOOR CONTOUR ILLUMINATION LAMP
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
RIGHT REAR DOOR CONTOUR ILLUMINATION LAMP
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
RIGHT REAR EXTERIOR DOOR HANDLE
RIGHT REAR EXTERIOR DOOR HANDLE COUPLING POINT
RIGHT REAR EXTERIOR DOOR HANDLE ILLUMINATION BULB
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/GRN WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
YEL/GRN WIRE
Go to component -> Instrument illumination circuit (1 of 3) -> INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH
