Volkswagen Golf R VIII (2020-2024) front passenger seat backrest coupling point Wiring diagram
This page shows the only wiring diagram for the component.front passenger seat backrest coupling point, which is found in the car Volkswagen Golf R VIII (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger seat backrest coupling point (1 of 1)
BRN WIRE
FRONT PASSENGER BACKREST ADJUSTMENT MOTOR
FRONT PASSENGER BACKREST ADJUSTMENT SWITCH
FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD
FRONT PASSENGER SEAT BACKREST COUPLING POINT
FRONT PASSENGER SEAT COUPLING POINT
FUSE PANEL 5
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
RED/BLK WIRE
RIGHT FRONT SEAT ADJUSTMENT CONTROL HEAD
W/ SEAT VENTILATION
W/O SEAT VENTILATION
Go to component -> Passenger power seat circuit -> FRONT PASSENGER SEAT BACKREST COUPLING POINT
