Volkswagen Golf R VIII (2020-2024) coupling point in engine/motor compartment Wiring diagrams
This page contains all the electrical diagrams for the component. coupling point in engine/motor compartment, in which he is found in the car Volkswagen Golf R VIII (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram coupling point in engine/motor compartment (1 of 4)
ABS CONTROL MODULE
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4
BLK WIRE
BLK/VIO WIRE
BRAKE BOOSTER
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
COOLING OIL VALVE
COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
DIFFERENTIAL LOCKS CONTROL MODULE
DUAL-CLUTCH TRANSMISSION MECHATRONIC
ENGINE CONTROLS SYSTEM
ENGINE/MOTOR CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
FUSE 12
FUSE 7
FUSE PANEL B
HOT AT ALL TIMES
HYDRAULIC PRESSURE SENSOR 1
HYDRAULIC PRESSURE SENSOR 2
LEFT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
MAIN PRESSURE VALVE
ORG/ WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED/GRY WIRE
RED/YEL WIRE
SUB-TRANSMISSION 1 VALVE 1
SUB-TRANSMISSION 1 VALVE 2
SUB-TRANSMISSION 1 VALVE 3
SUB-TRANSMISSION 1 VALVE 4
SUB-TRANSMISSION 2 VALVE 1
SUB-TRANSMISSION 2 VALVE 2
SUB-TRANSMISSION 2 VALVE 3
SUB-TRANSMISSION 2 VALVE 4
TEMPERATURE SENSOR (IN CONTROL MODULE)
TRANSMISSION COOLANT VALVE
TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP 1
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SPEED SENSOR 1
TRANSMISSION INPUT SPEED SENSOR 2
VIO/WHT WIRE
Go to component -> A/t circuit (1 of 2) -> COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
Wiring diagram coupling point in engine/motor compartment (2 of 4)
AUXILIARY HEATER CONTROL MODULE
BOTTOM LEFT COUPLING POINT IN INTERIOR
COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
DRIVER SEAT ADJUSTMENT CONTROL MODULE
DUAL-CLUTCH TRANSMISSION MECHATRONIC
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
FRONT PASSENGER DOOR CONTROL MODULE
GRN WIRE
GRY WIRE
HEATING, AIR CONDITIONING CONTROL MODULE
INSTRUMENT CLUSTER
LEFT COUPLING POINT IN LUGGAGE COMPARTMENT
LEFT FRONT SEAT COUPLING STATION
ORG/ WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PARKING LOCK ACTUATOR
RIGHT FRONT DOOR COUPLING POINT
SELECTOR MECHANISM
SUNROOF CONTROL MODULE
SUNROOF COUPLING POINT
TOWING RECOGNITION CONTROL MODULE
TRANSMISSION CONTROL MODULE
TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP 1
VIO WIRE
W/ TRAILER SETUP
W/O TRAILER SETUP
WHT WIRE
WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
Go to component -> Computer data lines circuit (3 of 4) -> COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
Wiring diagram coupling point in engine/motor compartment (3 of 4)
ADAPTIVE CRUISE CONTROL MODULE
AIR QUALITY SENSOR
ALARM HORN
ANTI-THEFT ALARM SYSTEM HORN
BATTERY
BATTERY MONITORING CONTROL MODULE
BLK WIRE
BRAKE BOOSTER
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
BURGLARY PROTECTION CONTROL MODULE 2
CLUTCH POSITION SENSOR
COOLANT RECIRCULATION PUMP
COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
DIFFERENTIAL LOCKS CONTROL MODULE
DUAL-CLUTCH TRANSMISSION MECHATRONIC
FUSE PANEL B STARTER RELAY 1
HOOD CONTACT SWITCH 2
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
LEFT FRONT FOG LAMP BULB
LEFT FRONT HEADLAMP
LEFT FRONT RADIATOR GRILLE FIBER OPTIC CABLE FOR CONTOUR ILLUMINATION
LEFT HORN
LEFT WASHER NOZZLE HEATER
NCA WIRE
OIL LEVEL THERMAL SENSOR
POWER STEERING CONTROL MODULE
RIGHT FRONT RADIATOR GRILLE FIBER OPTIC CABLE FOR CONTOUR ILLUMINATION
RIGHT WASHER NOZZLE HEATER
STRUCTURE BORNE SOUND CONTROL MODULE
TRANSMISSION
TRANSMISSION CONTROL MODULE
TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP 1
WIPER MOTOR CONTROL MODULE
Go to component -> Ground distribution circuit (1 of 8) -> COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
Wiring diagram coupling point in engine/motor compartment (4 of 4)
