Volkswagen Golf R VIII (2020-2024) control module power supply relay energized Wiring diagram
This page shows the only wiring diagram for the component.control module power supply relay energized, which is found in the car Volkswagen Golf R VIII (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram control module power supply relay energized (1 of 1)
BLK WIRE
BLK/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
ENGINE/MOTOR CONTROL MODULE
FUSE 2
FUSE 23
FUSE 24
FUSE 6
FUSE PANEL A
FUSE PANEL B
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE
ORG/BRN WIRE
ORG/GRY WIRE
OUTSIDE AIR TEMPERATURE SENSOR
RADIATOR FAN
RADIATOR FAN CONTROL MODULE
RED/BLK WIRE
RED/GRN WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
YEL/VIO WIRE
Go to component -> Cooling fan circuit -> CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
