Volkswagen Golf R VIII (2020-2024) air conditioning system engine controls, anti-lock brakes systems Wiring diagram
This page shows the only wiring diagram for the component.air conditioning system engine controls, anti-lock brakes systems, which is found in the car Volkswagen Golf R VIII (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air conditioning system engine controls, anti-lock brakes systems (1 of 1)
AIR CONDITIONING SYSTEM ENGINE CONTROLS, ANTI-LOCK BRAKES SYSTEMS
ANTI-THEFT SYSTEM
BLK/RED WIRE
BLK/VIO WIRE
BRN WIRE
CRUISE CONTROL SYSTEM
DEFOGGER SYSTEM
FUSE 35
FUSE 6
FUSE PANEL C (LEFT SIDE OF DASH)
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
HEADLIGHTS, INTERIOR LIGHTS SYSTEMS
HOT AT ALL TIMES
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH )
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WIPER/WASHER SYSTEM
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Vehicle electrical system control module circuit (2 of 2) -> AIR CONDITIONING SYSTEM ENGINE CONTROLS, ANTI-LOCK BRAKES SYSTEMS
