Volkswagen Golf R VII facelift (2017-2020) front passenger occupant detection system control module Wiring diagram
This page shows the only wiring diagram for the component.front passenger occupant detection system control module, which is found in the car Volkswagen Golf R VII facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger occupant detection system control module (1 of 1)
BLK WIRE
BRN WIRE
CD PLAYER
COUPLING POINT ON ROOF
DRIVER DOOR CONTROL MODULE
DRIVER DOOR LOCK UNIT
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FRESH AIR BLOWER CONTROL MODULE
FRONT INFORMATION DISPLAY CONTROL HEAD
FRONT PASSENGER BACKREST HEATING ELEMENT
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER DOOR LOCK UNIT
FRONT PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE
FRONT PASSENGER SIDE HEATED SEAT
GLOVE COMPARTMENT LAMP
GRY WIRE
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT DOOR COUPLING POINT
LEFT REAR DOOR COUPLING POINT
LEFT REAR DOOR LOCK UNIT
LEFT REAR WINDOW REGULATOR MOTOR
MOBILE COMMUNICATION 2-WAY SIGNAL AMPLIFIER
POWER SUNROOF CONTROL MODULE
REAR VIEW CAMERA
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT FOOTWELL LAMP
RIGHT FRONT SEAT COUPLING STATION
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR DOOR LOCK UNIT
RIGHT REAR WINDOW REGULATOR MOTOR
STORAGE COMPARTMENT W/ CELL PHONE INTERFACE
TELEMATICS BUTTON MODULE
TV TUNER
USB DISTRIBUTOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
Go to component -> Ground distribution circuit (2 of 5) -> FRONT PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE
