Volkswagen Golf R VII facelift (2017-2020) epc throttle drive angle angle sensor 2 Wiring diagram

BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CHARGE AIR PRESSURE ACTUATOR POSITION SENSOR ENGINE SPEED SENSOR ENGINE TEMPERATURE CONTROL ACTUATOR EPC THROTTLE DRIVE ANGLE ANGLE SENSOR 1 EPC THROTTLE DRIVE ANGLE ANGLE SENSOR 2 EPC THROTTLE VALVE FUEL INJECTOR CYLINDERS (1, 2, 3, 4 CYLINDERS HEAD INTAKE PORT) FUEL PRESSURE SENSOR GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE INTAKE MANIFOLD SENSOR LEFT COUPLING POINT IN ENGINE COMPARTMENT RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE THROTTLE VALVE CONTROL MODULE (INTAKE MANIFOLD INLET) TOP RIGHT COUPLING POINT ON ENGINE VIO/GRN WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/VIO WIRE
