Volkswagen Golf R VII facelift (2017-2020) cruise control set button, cruise control switch Wiring diagram
This page shows the only wiring diagram for the component.cruise control set button, cruise control switch, which is found in the car Volkswagen Golf R VII facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control set button, cruise control switch (1 of 1)
AIR BAG SPIRAL SPRING/RETURN SPRING W/ SLIP RING
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SET BUTTON, CRUISE CONTROL SWITCH
ENGINE CONTROLS SYSTEM
FUSE 2
FUSE 9
FUSE PANEL C
GRN WIRE
GRY WIRE
HORNS SYSTEM
HOT AT ALL TIMES
IGNITION SWITCH KEYLOCK SOLENOID
IGNITION/STARTER SWITCH
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
STEERING COLUMN ASSEMBLY
STEERING COLUMN ELECTRONICS CONTROL MODULE
SUPPLEMENTAL RESTRAINTS SYSTEM
TRANSMISSIONS SYSTEM
TURN SIGNAL SWITCH
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE CIRCUIT
VIO/BLU WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Steering column electronic systems control module circuit (1 of 2) -> CRUISE CONTROL SET BUTTON, CRUISE CONTROL SWITCH
