Volkswagen Golf GTI VIII (2019-2024) control module for emergency call module, communication unit Wiring diagram
This page shows the only wiring diagram for the component.control module for emergency call module, communication unit, which is found in the car Volkswagen Golf GTI VIII (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram control module for emergency call module, communication unit (1 of 1)
BRN WIRE
BRN/YEL WIRE
CENTRAL LOCKING BUTTON
CENTRAL LOCKING SAFE INDICATOR LAMP
COMPUTER DATA LINES SYSTEM
CONTROL MODULE FOR EMERGENCY CALL MODULE, COMMUNICATION UNIT
DRIVER DOOR CONTROL MODULE
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER EXTERIOR DOOR HANDLE
DRIVER SIDE EXTERIOR DOOR HANDLE ILLUMINATION LAMP
EXTERIOR REAR VIEW MIRROR ADJUSTER
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR DOOR HANDLE
FRONT PASSENGER EXTERIOR DOOR HANDLE ILLUMINATION LAMP
FRONT PASSENGER POWER WINDOW BUTTON
FRONT ROOF MODULE
FUEL FILLER DOOR RELEASE BUTTON
FUSE 26
FUSE 9
FUSE PANEL C
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT EXTERIOR DOOR HANDLE COUPLING POINT
MIRROR ADJUSTMENT SWITCH ILLUMINATION BULB
ORG/BRN WIRE
PUSH BUTTON ILLUMINATION BULB
PUSH BUTTON ILLUMINATION SWITCH
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT EXTERIOR DOOR HANDLE COUPLING POINT
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL/GRN WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> CONTROL MODULE FOR EMERGENCY CALL MODULE, COMMUNICATION UNIT
