Volkswagen Golf GTI VII facelift (2017-2020) Ground distribution circuit

A/C COMPRESSOR REGULATOR VALVE ABS CONTROL MODULE ADAPTIVE CRUISE CONTROL MODULE AIR QUALITY SENSOR ALARM HORN ANTI-THEFT ALARM SYSTEM HORN BATTERY BATTERY MONITORING CONTROL MODULE BLK WIRE BRAKE FLUID LEVEL WARNING SWITCH BRAKE LAMP SWITCH BRN WIRE CLUTCH POSITION SENSOR CORNERING LAMP, HEADLAMP RANGE CONTROL MODULE DUAL-CLUTCH TRANSMISSION MECHATRONIC HEADLAMP WASHER SYSTEM COUPLING POINT HEADLAMP WASHER SYSTEM PUMP HEATER SUPPORT PUMP HIGH TONE HORN IGNITION COIL 1 W/ POWER OUTPUT STAGE IGNITION COIL 2 W/ POWER OUTPUT STAGE IGNITION COIL 3 W/ POWER OUTPUT STAGE IGNITION COIL 4 W/ POWER OUTPUT STAGE LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT LEFT FRONT FOG LAMP LEFT FRONT HEADLAMP LEFT WASHER NOZZLE HEATER M/T NCA WIRE OIL LEVEL THERMAL SENSOR POWER STEERING CONTROL MODULE RIGHT FRONT BRAKE PAD WEAR SENSOR RIGHT HEADLIGHT ASSEMBLY RIGHT WASHER NOZZLE HEATER STRUCTURE BORNE SOUND CONTROL MODULE TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP 1 W/ HID HEADLAMPS W/O HID HEADLAMPS WIPER MOTOR CONTROL MODULE YEL WIRE

ACCESS/ START SYSTEM INTERFACE BLK WIRE BRN WIRE CD PLAYER CELLULAR TELEPHONE PREPARATION CONTROL HEAD COUPLING POINT ON ROOF DRIVER DOOR CONTROL MODULE DRIVER DOOR LOCK UNIT EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE FRESH AIR BLOWER CONTROL MODULE FRONT INFORMATION DISPLAY CONTROL HEAD FRONT PASSENGER BACKREST HEATING ELEMENT FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR LOCK UNIT FRONT PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE FRONT PASSENGER SEAT HEATING ELEMENT FRONT PASSENGER SIDE HEATED SEAT GLOVE COMPARTMENT LAMP GRY WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT FRONT DOOR COUPLING POINT LEFT REAR DOOR COUPLING POINT LEFT REAR DOOR LOCK UNIT LEFT REAR WINDOW REGULATOR MOTOR MOBILE COMMUNICATION 2-WAY SIGNAL AMPLIFIER POWER SUNROOF CONTROL MODULE REAR VIEW CAMERA RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT FOOTWELL LAMP RIGHT FRONT SEAT COUPLING STATION RIGHT REAR DOOR COUPLING POINT RIGHT REAR DOOR LOCK UNIT RIGHT REAR WINDOW REGULATOR MOTOR ROOF COUPLING POINT TELEPHONE BASEPLATE TV TUNER USB DISTRIBUTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ SPORT SEATS W/O SPORT SEATS WHT WIRE

ANTI-THEFT ALARM SYSTEM SENSOR BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE BRN/GRN WIRE CENTER CONSOLE SWITCH MODULE 2 COUPLING POINT ON ROOF DATA BUS ON BOARD DIAGNOSTIC INTERFACE DIAGNOSTIC CONNECTION DRIVER ASSISTANCE SYSTEMS FRONT CAMERA DRIVER BACKREST HEATING ELEMENT DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT HEATING ELEMENT DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SIDE HEATED SEAT DRIVER VANITY MIRROR LAMP CONTACT SWITCH ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE FROM LEFT REAR DOOR COUPLING POINT (DIAGRAM 2 OF 5) FRONT INTERIOR LAMP FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH FUSE PANEL C HEADLAMP RANGE CONTROL, INSTRUMENT ILLUMINATION REGULATOR INSTRUMENT CLUSTER INTERIOR REAR VIEW MIRROR LEFT FRONT FOOTWELL LAMP LEFT FRONT HEADLAMP LEFT FRONT SEAT COUPLING STATION MASSAGE FUNCTION CONTROL MODULE PARALLEL PARKING ASSISTANCE CONTROL MODULE/ PARKING AID CONTROL MODULE RAIN/LIGHT RECOGNITION SENSOR REAR INTERIOR LAMP RIGHT FRONT HEADLAMP ROTARY LIGHT SWITCH SOCKETS RELAY STEERING COLUMN ELECTRONICS CONTROL MODULE TERMINAL 15 POWER SUPPLY RELAY VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ SPORT SEATS W/O HID HEADLAMPS W/O SPORT SEATS

ALL WHEEL DRIVE COUPLING POINT ALL- WHEEL DRIVE CONTROL MODULE AM FREQUENCY FILTER BLK WIRE BRN WIRE CENTER CONSOLE SWITCH MODULE 1 ELECTRO- MECHANICAL PARKING BRAKE BUTTON ELECTRONIC DAMPING CONTROL MODULE EMERGENCY FLASHER BUTTON ENGINE SOUND GENERATOR CONTROL MODULE EXHAUST DOOR CONTROL UNIT 2 EXHAUST DOOR CONTROL UNIT COUPLING POINT HEATER, A/C CONTROLS CLIMATRONIC CONTROL MODULE HIGH-MOUNTED BRAKE LAMP LEFT "C" PILLAR) LEFT TAIL LAMP LEFT TAIL LAMP 2 PARKING BRAKE PRESSURE SWITCH REAR LID COUPLING POINT REAR LID HANDLE RELEASE BUTTON REAR LID LOCK UNIT REAR WINDOW DEFOGGER REAR WINDOW WIPER MOTOR RIGHT TAIL LAMP RIGHT TAIL LAMP 2 SELECTOR LEVER START SYSTEM BUTTON W/ NAVIGATION W/ REAR VIEW CAMERA W/O NAVIGATION W/O REAR VIEW CAMERA WHT WIRE

BLIND SPOT DETECTION CONTROL MODULE BLIND SPOT DETECTION CONTROL MODULE 2 BRN WIRE BRN/GRN WIRE COUPLING POINT IN THE LEFT FRONT DOOR COUPLING POINT IN THE RIGHT FRONT DOOR DIGITAL SOUND SYSTEM CONTROL MODULE DRIVER EXTERIOR REAR VIEW MIRROR DRIVER SEAT ADJUSTMENT CONTROL MODULE ENGINE CONTROL MODULE EXHAUST DOOR CONTROL UNIT EXHAUST DOOR CONTROL UNIT COUPLING POINT FUEL PUMP CONTROL MODULE HOOD CONTACT SWITCH LEFT FRONT DOOR COUPLING POINT LEFT FRONT SEAT COUPLING STATION LEFT LICENSE PLATE LAMP LOW TONE HORN PASSENGER EXTERIOR REAR VIEW MIRROR RADIATOR FAN REFRIGERANT CIRCUIT PRESSURE SENSOR RIGHT COUPLING POINT IN LUGGAGE COMPARTMENT RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT FOG LAMP RIGHT FRONT HEADLAMP RIGHT LICENSE PLATE LAMP RIGHT TAIL LAMP W/ HID HEADLAMPS W/O HID HEADLAMPS
