Computer data lines circuit for Volkswagen Golf GTI VII facelift (2017-2020)

ALARM HORN ANTI-THEFT ALARM SYSTEM SENSOR BATTERY MONITORING CONTROL MODULE BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLU WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR BRN WIRE CLIMATRONIC CONTROL MODULE COUPLING POINT ON ROOF DATA BUS ON BOARD DIAGNOSTIC INTERFACE DIAGNOSTIC CONNECTION (LEFT SIDE OF DASH) DRIVER DOOR CONTROL MODULE EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE FUSE 35 FUSE 5 FUSE 8 FUSE PANEL C GENERATOR W/ VOLTAGE REGULATOR GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT LEFT FRONT DOOR COUPLING POINT LEFT REAR DOOR COUPLING POINT LEFT REAR WINDOW REGULATOR MOTOR ORG/BRN WIRE ORG/GRN WIRE ORG/RED WIRE OVERHEAD CONSOLE REAR OF ENGINE COMPT) RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE SUNROOF CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/WHT WIRE WHT WIRE WIPER MOTOR CONTROL MODULE

ADAPTIVE CRUISE CONTROL MODULE AIR BAG CONTROL MODULE (CENTER OF DASH) BLIND SPOT DETECTION CONTROL MODULE BLK WIRE BLK/VIO WIRE BLU WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR CENTER OF WINDSHIELD) CORNERING LAMP, HEADLAMP RANGE CONTROL MODULE DRIVER ASSISTANCE SYSTEMS FRONT CAMERA DUAL-CLUTCH TRANSMISSION MECHATRONIC ENGINE/MOTOR CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) FRONT PASSENGER DOOR CONTROL MODULE GRN WIRE GRY WIRE INTERIOR REAR VIEW MIRROR LEFT FRONT HEADLAMP ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE ORG/WHT WIRE RAIN/LIGHT RECOGNITION SENSOR REAR OF ENGINE COMPT) RED/VIO WIRE RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT HEADLAMP SELECTOR LEVER STRUCTURE BORNE SOUND CONTROL MODULE VIO WIRE VIO/WHT WIRE W/ HIGH BEAM ASSIST WHT WIRE

ABS CONTROL MODULE ALL WHEEL DRIVE COUPLING POINT ALL- WHEEL DRIVE CONTROL MODULE BLK WIRE BLK/VIO WIRE BOTTOM LEFT COUPLING POINT IN INTERIOR DIFFERENTIAL LOCKS CONTROL MODULE ELECTRONIC DAMPING CONTROL MODULE ENGINE SOUND GENERATOR CONTROL MODULE FRONT INFORMATION DISPLAY CONTROL HEAD FUSE 18 FUSE PANEL B HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT "C" PILLAR) LEFT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE PARALLEL PARKING ASSISTANCE CONTROL MODULE/ PARKING AID CONTROL MODULE POWER STEERING CONTROL MODULE RED/VIO WIRE RIGHT REAR DOOR COUPLING POINT RIGHT REAR WINDOW REGULATOR MOTOR VIO WIRE VIO/WHT WIRE WHT WIRE
