Power window circuit for Volkswagen EuroVan T4 facelift (1997-2003)
Power window circuit
BLK/BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
DRIVER'S SIDE POWER WINDOW SWITCH
FUSE 14
FUSE 43
FUSE/ RELAY PANEL (BEHIND LEFT SIDE OF DASH)
GRN/WHT WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILLUMINATION
INTERIOR LIGHTS SYSTEM, INSTRUMENT CLUSTER SYSTEM, EXTERIOR LIGHTS SYSTEM
LEFT FRONT POWER WINDOW CONTROL MODULE
LEFT FRONT WINDOW SWITCH
PASSENGER'S SIDE POWER WINDOW SWITCH
POWER WINDOW CIRCUIT BREAKER (ABOVE FUSE/ RELAY PANEL)
RED WIRE
RIGHT FRONT POWER WINDOW CONTROL MODULE
RIGHT FRONT WINDOW SWITCH
TV 5 JUNCTION CONNECTOR
WINDOW MOTOR
