Car Wiring Diagrams for Auxiliary battery circuit for Volkswagen EuroVan T4 facelift (1997-2003)

A/T AUXILIARY BATTERY BATTERY BATTERY CUT-OUT RELAY (BELOW DRIVER'S SEAT) BLK WIRE BLU WIRE BODY BRN WIRE FUSE/RELAY PANEL (BEHIND LEFT SIDE OF DASH) GENERATOR GENERATOR WARNING LIGHT GRN WIRE IGNITION SWITCH INSTRUMENT CLUSTER M/T PARK/NEUTRAL POSITION (PNP) RELAY (BEHIND CENTER OF DASH) POWER DISTRIBUTION CIRCUIT RED WIRE STARTER
