Volkswagen EuroVan T4 facelift (1997-2003) driver side heated outside mirror Wiring diagram
This page shows the only wiring diagram for the component.driver side heated outside mirror, which is found in the car Volkswagen EuroVan T4 facelift (1997-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side heated outside mirror (1 of 1)
AIR BAG CONTROL MODULE
BATTERY
BLK WIRE
BODY
BRN WIRE
CENTER INTERIOR LIGHT
CENTRAL LOCKING SYSTEM CONTROL MODULE
CIGARETTE LIGHTER
CLIMA- TRONIC CONTROL MODULE
DATA LINK CONNECTOR FOR DLC
DRIVER SIDE HEATED OUTSIDE MIRROR
DRIVER'S CABIN POWER SUNROOF CONTROL MODULE RIGHT FRONT MAP/READING LIGHT
DRIVER'S DOOR CENTRAL LOCKING SYSTEM MOTOR
DRIVER'S HEATED BACKREST
DRIVER'S HEATED SEAT CONTROL MODULE
DRIVER'S HEATED SEAT TEMP ELEMENT
EMERGENCY FLASHER SWITCH
ENGINE COOLANT TWO-WAY VACUUM VALVE
FAN RELAY
FRONT INTERIOR LIGHT
FUSE/RELAY PANEL (BEHIND LEFT SIDE OF DASH)
FUSE/RELAY PANEL (BEHIND LEFT SIDE OF DASH) CLIMA- TRONIC RELAY
GLOVE COMPT LIGHT
HEADLAMP CLEANING SYSTEM RELAY
HEADLIGHT WASHER PUMP
INTERIOR LIGHT W/ DELAY SWITCH
LEFT FRONT BRAKE PAD WEAR SENSOR
LEFT MIRROR MAGNETIC CLUTCH
LOAD REDUCTION RELAY II
MIRROR ADJUSTING SWITCH LIGHT
NCA WIRE
OUTLET 1
OUTLET 2
OUTLET 3
PASS- ENGER'S DOOR CENTRAL LOCKING SYSTEM MOTOR
PASS- ENGER'S HEATED BACKREST
PASS- ENGER'S HEATED SEAT CONTROL MODULE
PASS- ENGER'S HEATED SEAT TEMP ELEMENT
PASSENGER SIDE HEATED OUTSIDE MIRROR RIGHT MIRROR MAGNETIC CLUTCH
PASSENGER'S COMPARTMENT POWER SUNROOF CONTROL MODULE
REAR A/C CONTROL HEAD
RED WIRE
RIGHT REAR SLIDING DOOR CONTACT SWITCH
SWIVEL SEAT LOCK CONTROL MODULE
WARM AIR BLOWER CONTROL MODULE
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (2 of 3) -> DRIVER SIDE HEATED OUTSIDE MIRROR
