Power top/sunroof circuit for Volkswagen Eos I facelift (2010-2015)

BLU WIRE BRN WIRE BRN/BLK WIRE BRN/VIO WIRE BRN/WHT WIRE CENTRAL WINDOW REGULATOR SWITCH CLOSING ASSIST MOTOR COMFORT SYSTEM CENTRAL CONTROL MODULE COMFORT SYSTEM CENTRAL CONTROL MODULE (BEHIND GLOVE BOX) COMPUTER DATA LINES SYSTEM CONVERTIBLE OPERATION SWITCH CONVERTIBLE TOP CONTROL MODULE CONVERTIBLE TOP CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) DOOR CLOSING ASSIST CONTROL MODULE DOOR CLOSING ASSIST CONTROL MODULE (AT TRUNK LID LATCH) DRIVER DOOR CONTROL MODULE (IN DRIVER FRONT DOOR) FUSE FUSE 19 FUSE 28 54 FUSE 29 53 FUSE 32 FUSE PANEL FUSE PANEL B FUSE PANEL C GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE FUSE PANEL B (ON ELECTRONICS BOX) LEFT REAR DOOR CONTROL MODULE LEFT REAR DOOR CONTROL MODULE (IN LEFT REAR DOOR) LEFT REAR WINDOW FRAME LOCK SENSOR LEFT REAR WINDOW FRAME LOCK SENSOR (IN LEFT REAR WINDOW FRAME) LEFT ROOF PILLAR FRONT POSITION SENSOR LUGGAGE COVER CONTACT SWITCH ORG/BRN WIRE ORG/GRN WIRE PUSH BUTTON ILLUMINATION REAR WINDOW FRAME OPENING SENSOR REAR WINDOW FRAME OPENING SENSOR (IN LEFT REAR WINDOW FRAME) RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR DOOR CONTROL MODULE RIGHT REAR DOOR CONTROL MODULE (IN RIGHT REAR DOOR) RIGHT ROOF PILLAR FRONT POSITION SENSOR SUNROOF BUTTON SUNROOF CIRCUIT BREAKER SUNROOF SWITCH/ POWER TOP OPERATION SWITCH VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/WHT WIRE W/ ELECTRONICS BOX LOW W/ ELECTRONICS BOX HIGH WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE

BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE CONVERTIBLE TOP CONTROL MODULE CONVERTIBLE TOP HYDRAULIC PUMP CONVERTIBLE TOP HYDRAULIC PUMP, VALVES, TEMPERATURE SENSOR CONVERTIBLE TOP STORAGE SENSOR CONVERTIBLE TOP STORAGE SENSOR 2 GRN WIRE GRY WIRE HYDRAULIC PUMP TEMPERATURE SENSOR LEFT PARCEL SHELF LOCK SENSOR LEFT PARCEL SHELF LOCK SENSOR (LEFT SIDE OF LUGGAGE COMPT) LEFT ROOF PILLAR FLAP OPENING SENSOR LEFT ROOF PILLAR FLAP OPENING SENSOR (BEHIND LEFT SIDE PANEL) LEFT ROOF PILLAR LOCK SENSOR LEFT ROOF PILLAR LOCK SENSOR (FRONT OF LEFT ROOF RAIL, AT LATCH) NCA WIRE POWER CONVERTIBLE TOP VALVE 1 POWER CONVERTIBLE TOP VALVE 2 POWER CONVERTIBLE TOP VALVE 3 POWER SUNROOF CONTROL MODULE POWER SUNROOF CONTROL MODULE (BEHIND SUNROOF) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT PARCEL SHELF LOCK SENSOR RIGHT PARCEL SHELF LOCK SENSOR (RIGHT SIDE OF LUGGAGE COMPT) RIGHT REAR WINDOW FRAME LOCK SENSOR RIGHT REAR WINDOW FRAME LOCK SENSOR (IN RIGHT REAR WINDOW FRAME) RIGHT ROOF PILLAR FLAP OPENING SENSOR RIGHT ROOF PILLAR FLAP OPENING SENSOR (BEHIND RIGHT SIDE PANEL) RIGHT ROOF PILLAR LOCK SENSOR RIGHT ROOF PILLAR LOCK SENSOR (FRONT OF RIGHT ROOF RAIL, AT LATCH) SUNROOF MOTOR VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE YEL WIRE
