Rear view camera circuit for Volkswagen Eos I facelift (2010-2015)
Rear view camera circuit
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE (LEFT END OF DASH)
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
ORG/ WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
RADIO (OR) RADIO/ NAVIGATION DISPLAY CONTROL MODULE
REARVIEW CAMERA
RED/WHT WIRE
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
WHT WIRE
