Navigation circuit, premium for Volkswagen Eos I facelift (2010-2015)
Navigation circuit, premium (1 of 2)
AM/FM
BLK WIRE
BLU WIRE
BRN WIRE
CD CHANGER (IF EQUIPPED)
COMPUTER DATA LINES SYSTEM
DAB
EXTERNAL AUDIO SOURCE CONNECTOR
FUSE 28
FUSE 8
FUSE PANEL B
FUSE PANEL C
GPS
GPS ANTENNA, DIGITAL RADIO ANTENNA, RADIO ANTENNA 2, ANTENNA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
POWER DISTRIBUTION SYSTEM
RADIO/ NAVIGATION DISPLAY CONTROL MODULE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VOLTAGE STABILIZER
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Navigation circuit, premium (2 of 2)
AMPLIFIER
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE 18
FUSE PANEL B
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT BASS SPEAKER
LEFT FRONT MIDRANGE SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR BASS SPEAKER
LEFT REAR TREBLE SPEAKER
ORG/BRN WIRE
ORG/VIO WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT MIDRANGE SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR BASS SPEAKER
RIGHT REAR TREBLE SPEAKER
WHT WIRE
YEL WIRE
