Volkswagen Eos I facelift (2010-2015) oxygen heater sensor wiring diagram
This page shows the only wiring diagram for the component.oxygen heater sensor, which is found in the car Volkswagen Eos I facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
oxygen heater sensor wiring diagram (1 of 1)
A/T
AFTER THREE-WAY CATALYTIC CONVERTER
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH
BRN WIRE
CAMSHAFT ADJUSTMENT VALVE 1
CANISTER PURGE REGULATOR VALVE 1
CBFA
CBFA CCTA
CCTA
CLUTCH POSITION SENSOR
COOLANT CIRCULATION PUMP RELAY
COOLANT FAN CONTROL (FC) CONTROL MODULE
ENGINE COMPONENT POWER SUPPLY RELAY
ENGINE COMPONENT POWER SUPPLY RELAY (CBFA)
ENGINE COMPONENT POWER SUPPLY RELAY (CCTA)
ENGINE CONTROL MODULE (ECM)
ENGINE SECONDARY CONTROL AIR MODULE INJECTION (ECM) SOLENOID VALVE (CBFA)
EVAP CAMSHAFT ADJUSTMENT VALVE 1
EVAP CANISTER PURGE REGULATOR VALVE 1
FROM FUSE 19 (DIAGRAM 1 OF 5)
FROM FUSE PANEL B (DIAGRAM 1 OF 5)
FUEL PRESSURE REGULATOR VALVE
FUSE 10
FUSE 13
FUSE 14
FUSE 15
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE FUSE 13
FUSE PANEL B (ON ELECTRONICS BOX)
GRN WIRE
GRY WIRE
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
IGNITION/STARTER SWITCH
INTAKE MANIFOLD RUNNER CONTROL (IMRC) VALVE
INTAKE MANIFOLD WASTE- RUNNER CONTROL GATE (IMRC) VALVE BYPASS REGULATOR VALVE
LEAK DETECTION PUMP
M/T
MOTRONIC ENGINE CONTROL MODULE (ECM) POWER SUPPLY RELAY
NCA WIRE
OXYGEN HEATER SENSOR
OXYGEN HEATER SENSOR (CBFA)
OXYGEN SENSOR
OXYGEN SENSOR 2 HEATER, HEATED OXYGEN SENSOR 2
OXYGEN SENSOR HEATER, HEATED OXYGEN SENSOR
POWER SUPPLY RELAY 2 (TERMINAL 15)
POWER SUPPLY RELAY 2 (TERMINAL 15) (ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE)
RED WIRE
RED/BLK WIRE
SECONDARY AIR INJECTION PUMP RELAY
SECONDARY AIR INJECTION PUMP RELAY (CBFA) FUSE PANEL B (ON ELECTRONICS BOX)
SECONDARY AIR INJECTION SOLENOID VALVE
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (UNDER TOP OF STEERING COLUMN)
TO BRAKE LIGHT SWITCH (DIAGRAM 3 OF 5)
TO FUSE PANEL C (DIAGRAM 3 OF 5)
TURBO CHARGER RECIRCU- LATION VALVE
TURBO COOLANT CHARGER FAN RECIRCU- CONTROL LATION (FC) VALVE CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
WASTE GATE BYPASS REGULATOR VALVE
WHT WIRE
Go to component -> Power distribution circuit (2 of 5) -> OXYGEN HEATER SENSOR
