Volkswagen Eos I facelift (2010-2015) interior lights system computer data lines system wiring diagram
This page shows the only wiring diagram for the component.interior lights system computer data lines system, which is found in the car Volkswagen Eos I facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
interior lights system computer data lines system wiring diagram (1 of 1)
AUTOMATIC DIMMING INTERIOR REARVIEW MIRROR
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE SYSTEMS FRONT CAMERA
DRIVER AUTOMATIC DIMMING EXTERIOR REARVIEW MIRROR
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR)
DRIVER'S OUTSIDE MIRROR (IF EQUIPPED)
INTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
VIO/BLK WIRE
VIO/BRN WIRE
Go to component -> Automatic day/night mirror circuit, with high beam assist -> INTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM
