Volkswagen Eos I (2006-2011) Shift interlock circuit

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLU/VIO WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DIRECT SHIFT GEARBOX (DSG) MECHATRONIC ENGINE CONTROL MODULE (ECM) FUSE 14 FUSE 6 FUSE PANEL GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED FUSE PANEL FUSE 2 IGNITION SWITCH KEY LOCK SOLENOID (A/T) NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE SELECTOR LEVER PARK POSITION LOCK SWITCH SHIFT LOCK SOLENOID STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE TRANSMISSION RANGE (TR) DISPLAY VIO WIRE VIO/BLK WIRE VIO/BRN WIRE VIO/RED WIRE WHT/GRN WIRE YEL WIRE
