Radio/navigation circuit, rcd 500 with navigation, rns 300, rns mfd 2 dvd dynaudio for Volkswagen Eos I (2006-2011)

AM/FM ANTENNA (RIGHT SIDE ANTENNA SELECTION CONTROL MODULE (W/ NAVIGATION) (UNDER FRONT PASSENGER'S SEAT) BLK WIRE BLU WIRE BRN WIRE CD CHANGER (IF EQUIPPED) COMPUTER DATA LINES SYSTEM DIGITAL SATELLITE RADIO TUNER (EXCEPT RCD 500) EXCEPT RCD 500 EXTERNAL AUDIO SOURCE CONNECTOR FUSE 18 FUSE 17 GPS GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL FUSE 8 NCA WIRE OF TRUNK LID) ORG/BRN WIRE ORG/VIO WIRE RADIO/NAVIGATION DISPLAY CONTROL MODULE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SAT VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/RED WIRE VIO/WHT WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

AMPLIFIER BASS SPEAKER BLU WIRE BLU/BLK WIRE BLU/VIO WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE LEFT FRONT BASS SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR TREBLE SPEAKER ORG/BRN WIRE ORG/VIO WIRE RED WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR RIGHT REAR TREBLE SPEAKER WHT WIRE YEL WIRE
