Radio circuit, rcd 500 dynaudio & rcd 310/rcd510 for Volkswagen Eos I (2006-2011)

AM/FM BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE CD CHANGER COMPUTER DATA LINES SYSTEM DAB EXTERNAL AUDIO SOURCE CONNECTOR FUSE 8 GRN WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL FUSE 18 LEFT FRONT BASS SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR TREBLE SPEAKER NCA WIRE OPERATING ELECTRONIC, TELEPHONE CONTROL MODULE (W/ TELEPHONE) ORG/BRN WIRE ORG/VIO WIRE RADIO RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR TREBLE SPEAKER TELEPHONE TRANSCEIVER (W/ CELLULAR TELEPHONE) (UNDER FRONT PASSENGER'S SEAT) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) W/O DYNAUDIO SOUND W/O SOUNDS SYSTEM DYNAUDIO W/ SOUNDS SYSTEM DYNAUDIO W/ DYNAUDIO SOUND WHT WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

AMPLIFIER BLU WIRE BLU/BLK WIRE BLU/VIO WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE LEFT FRONT BASS SPEAKER (W/ DYNAUDIO SOUND) LEFT FRONT MIDRANGE SPEAKER (W/ DYNAUDIO SOUND) LEFT FRONT TREBLE SPEAKER (W/ DYNAUDIO SOUND) LEFT REAR BASS SPEAKER (W/ DYNAUDIO SOUND) LEFT REAR TREBLE SPEAKER (W/ DYNAUDIO SOUND) ORG/BRN WIRE ORG/VIO WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE WHT WIRE YEL WIRE
