Convertible top circuit for Volkswagen Eos I (2006-2011)

BLU WIRE BRN WIRE BRN/BLK WIRE BRN/VIO WIRE CENTRAL WINDOW REGULATOR SWITCH CLOSING ASSIST MOTOR COMFORT SYSTEM CENTRAL CONTROL MODULE (BEHIND GLOVE BOX) COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) CONVERTIBLE TOP OPERATION SWITCH DOOR CLOSING ASSIST CONTROL MODULE (AT TRUNK LID LATCH) FUSE 19 FUSE 32 FUSE PANEL GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL A FUSE 7 HOT AT ALL TIMES FUSE PANEL B FUSE 29 LEFT REAR DOOR CONTROL MODULE LEFT REAR WINDOW FRAME LOCK SENSOR (IN LEFT REAR WINDOW FRAME) LUGGAGE COVER CONTACT SWITCH ORG/BRN WIRE ORG/GRN WIRE PUSH BUTTON ILLUMINATION REAR WINDOW FRAME OPENING SENSOR (IN LEFT REAR WINDOW FRAME) RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR DOOR CONTROL MODULE SUNROOF BUTTON SUNROOF CIRCUIT BREAKER SUNROOF SWITCH/ CONVERTIBLE TOP OPERATION SWITCH VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE

BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE CONVERTIBLE TOP CONTROL MODULE CONVERTIBLE TOP HYDRAULIC PUMP CONVERTIBLE TOP HYDRAULIC PUMP, VALVES, TEMPERATURE SENSOR GRN WIRE GRY WIRE HYDRAULIC PUMP TEMPERATURE SENSOR LEFT PARCEL SHELF LOCK SENSOR (LEFT SIDE OF LUGGAGE COMPT) LEFT ROOF PILLAR FLAP OPENING SENSOR (BEHIND LEFT SIDE PANEL) LEFT ROOF PILLAR LOCK SENSOR (FRONT OF LEFT ROOF RAIL, AT LATCH) NCA WIRE POWER CONVERTIBLE TOP VALVE 1 POWER CONVERTIBLE TOP VALVE 2 POWER CONVERTIBLE TOP VALVE 3 POWER SUNROOF CONTROL MODULE (BEHIND SUNROOF) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT PARCEL SHELF LOCK SENSOR (RIGHT SIDE OF LUGGAGE COMPT) RIGHT REAR WINDOW FRAME LOCK SENSOR (IN RIGHT REAR WINDOW FRAME) RIGHT ROOF PILLAR FLAP OPENING SENSOR (BEHIND RIGHT SIDE PANEL) RIGHT ROOF PILLAR LOCK SENSOR (FRONT OF RIGHT ROOF RAIL, AT LATCH) SUNROOF MOTOR TOP STOWAGE SENSOR (LEFT SIDE OF LUGGAGE COMPT) TOP STOWAGE SENSOR 2 VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE YEL WIRE
