Volkswagen Eos I (2006-2011) Power seats circuit

BACKREST ADJUST BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE DRIVER'S BACKREST ADJUSTMENT MOTOR DRIVER'S BACKREST STOP SWITCH (AFT) DRIVER'S BACKREST STOP SWITCH (FORE) DRIVER'S ENTRY ASSISTANCE BUTTON DRIVER'S ENTRY ASSISTANCE CONTROL MODULE (UNDER DRIVER'S SEAT) DRIVER'S POWER SEAT SWITCH DRIVER'S SEAT FORE/AFT ADJUSTMENT MOTOR/SENSOR (UNDER DRIVER'S SEAT) DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR (UNDER DRIVER'S SEAT) DRIVER'S SEAT INCLINATION ADJUSTMENT MOTOR (UNDER DRIVER'S SEAT) FORE/AFT HEIGHT ADJUST ADJUST GRN WIRE GRY WIRE NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE TILT ADJUST VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

BACKREST ADJUST BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL MODULE (UNDER FRONT PASSENGER'S SEAT) FORE/AFT ADJUST FRONT PASSENGER'S BACKREST ADJUSTMENT MOTOR FRONT PASSENGER'S BACKREST STOP SWITCH (AFT) FRONT PASSENGER'S BACKREST STOP SWITCH (FORE) FRONT PASSENGER'S ENTRY ASSISTANCE FRONT PASSENGER'S ENTRY ASSISTANCE BUTTON FRONT PASSENGER'S SEAT HEIGHT ADJUSTMENT MOTOR (UNDER FRONT PASSENGER'S SEAT) GRN WIRE GRY WIRE HEIGHT ADJUST NCA WIRE ORG/BRN WIRE ORG/GRN WIRE PASSENGER'S POWER SEAT SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE TILT ADJUST VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE
