Power door locks circuit for Volkswagen Eos I (2006-2011)

ALARM HORN ALARM HORN RELAY ANTI THEFT IMMOBILIZER READING COIL (RIGHT SIDE OF STEERING COLUMN) ANTI-THEFT ENGINE DISABLE INDICATOR ANTI-THEFT IMMOBILIZER CONTROL MODULE BLK/VIO WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR CENTRAL LOCKING LOCK UNIT DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR) DRIVER'S INTERIOR LOCK BUTTON EARLY PRODUCTION LATE PRODUCTION FUSE 12 FUSE 17 FUSE 2 FUSE 6 FUSE PANEL GRN WIRE GRN/WHT WIRE GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE MIRRORS SYSTEM ORG/BRN WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM POWER WINDOWS SYSTEM RADAR INTERIOR MONITORING CONTROL MODULE 1 (UNDER REAR OF CENTER CONSOLE) RADAR INTERIOR MONITORING CONTROL MODULE 2 (UNDER CENTER OF REAR SEAT) REAR LID CENTRAL LOCKING REMOTE LOCK SAFE INDICATOR KEY SWITCH LAMP REAR LID FUEL TANK REMOTE CONTROL LID UNLOCK LOCK SWITCH BUTTON REAR LID REMOTE CONTROL LOCK SWITCH/ FUEL TANK LID UNLOCK SWITCH ASSEMBLY RED/YEL WIRE VEHICLE INCLINATION SENSOR (BEHIND RIGHT SIDE OF DASH) VIO WIRE VIO/GRY WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE YEL WIRE

BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/YEL WIRE CENTRAL LOCKING, ANTI-THEFT ALARM SYSTEM ANTENNA COMFORT SYSTEM CENTRAL CONTROL MODULE (BEHIND GLOVE BOX) COMPUTER DATA LINES SYSTEM FRONT HOOD SWITCH FRONT PASSENGER'S DOOR CENTRAL LOCKING LOCK UNIT FRONT PASSENGER'S INTERIOR LOCK SWITCH FUEL TANK LID UNLOCK MOTOR (RIGHT SIDE OF LUGGAGE COMPT) FUSE 38 FUSE PANEL GRN WIRE GRY WIRE HOT AT ALL TIMES NCA WIRE ORG/BRN WIRE ORG/GRN WIRE PASSENGER COMPARTMENT MONITORING SWITCH PASSENGER'S DOOR CONTROL MODULE (IN PASSENGER'S FRONT DOOR) REAR LID HANDLE UNLOCK SWITCH REAR LID LOCK UNIT (CENTER REAR OF TRUNK LID) RED/BLK WIRE RED/BLU WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT DOOR WINDOW SWITCH VEHICLE ELECTRICAL SYSTEMS CONTROL MODULE (UNDER LEFT SIDE OF DASH) VIO WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE YEL WIRE
