Headlights circuit, with high intensity gas discharge headlights for Volkswagen Eos I (2006-2011)

BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM EARLY PRODUCTION LATE PRODUCTION FOG LAMP SWITCH FUSE 1 FUSE 13 FUSE 2 FUSE 5 FUSE 6 FUSE 15 FUSE PANEL GRY WIRE GRY/WHT WIRE GRY/YEL WIRE HEADLAMP DIMMER/ FLASHER SWITCH HIGH BEAM IND HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT CORNERING LAMP LEFT DYNAMIC CORNERING LIGHT MOTOR LEFT FRONT FOG LAMP LEFT HEADLAMP ASSEMBLY LEFT HEADLAMP BEAM ADJUSTMENT MOTOR LEFT HEADLAMP POWER OUTPUT STAGE LEFT HIGH INTENSITY GAS DISCHARGE LAMP CONTROL MODULE LEFT HIGH- INTENSITY GAS DISCHARGE LAMP LEFT LOW BEAM REFLECTOR MOTOR LEFT REAR FOG LAMP LEFT SWIVEL MODULE POSITION SENSOR LIGHT SWITCH NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE REAR FOG LAMP IND REAR FOG LAMP SWITCH (IF EQUIPPED) RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT FOG LAMP STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE TURN SIGNAL SWITCH/ HEADLAMP DIMMER/ FLASHER SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLK WIRE CONTROL MODULE (BEHIND GLOVE BOX) HEADLIGHT RANGE/ CORNERING LIGHT LEFT REAR LEVEL CONTROL SYSTEM SENSOR ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE RED WIRE RED/BLK WIRE RIGHT CORNERING LAMP (EARLY PRODUCTION) RIGHT CORNERING LAMP (LATE PRODUCTION) RIGHT DYNAMIC CORNERING LIGHT MOTOR RIGHT HEADLAMP ASSEMBLY RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HEADLAMP POWER OUTPUT STAGE RIGHT HIGH INTENSITY GAS DISCHARGE (HID) LAMP RIGHT HIGH INTENSITY GAS DISCHARGE LAMP CONTROL MODULE RIGHT LOW BEAM REFLECTOR MOTOR RIGHT SWIVEL MODULE POSITION SENSOR VIO WIRE WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
