Electronic power steering circuit, early production for Volkswagen Eos I (2006-2011)

12 13 COMPUTER DATA LINES SYSTEM BLK WIRE BLK/VIO WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL POWER STEERING INDICATOR LAMP ELECTRO- MECHANICAL POWER STEERING MOTOR HOT AT ALL TIMES FUSE PANEL FUSE 2 HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED FUSE PANEL FUSE 2 INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE POWER STEERING CONTROL MODULE (AT STEERING, ON SUBFRAME) RED WIRE STEERING ANGLE SENSOR (IF EQUIPPED) (UNDER TOP OF STEERING COLUMN) STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (BOTTOM OF STEERING COLUMN) STEERING TORQUE SENSOR (ABOVE STEERING RACK SUBFRAME) VIO WIRE YEL WIRE
