Volkswagen Eos I (2006-2011) lid lock unit) wiring diagram
This page shows the only wiring diagram for the component.lid lock unit), which is found in the car Volkswagen Eos I (2006-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
lid lock unit) wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (BEHIND GLOVE BOX)
COMPUTER DATA LINES SYSTEM
DRIVER'S MAKE-UP MIRROR LIGHT CONTACT SWITCH
DRIVER`S ILLUMINATED MAKE-UP MIRROR LIGHT
EARLY PRODUCTION
FRONT PASSENGER'S ILLUMINATED MAKE-UP MIRROR LIGHT
FRONT PASSENGER'S MAKE-UP MIRROR LIGHT CONTACT SWITCH
GARAGE DOOR OPENER CONTROL HEAD
GRN WIRE
GRY WIRE
LATE PRODUCTION
LEFT FRONT FOOTWELL ILLUMINATION
LEFT REAR FOOTWELL ILLUMINATION (W/O HEATED SEATS)
LID LOCK UNIT)
LUGGAGE COMPARTMENT LIGHT
LUGGAGE COMPARTMENT LIGHT SWITCH (INTEGRAL TO REAR
ORG/ WIRE
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RIGHT FRONT FOOTWELL ILLUMINATION
RIGHT REAR FOOTWELL ILLUMINATION (W/O HEATED SEATS)
WHT WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LID LOCK UNIT)
