Volkswagen Eos I (2006-2011) central window regulator switch Wiring diagrams

BLU WIRE BRN WIRE BRN/BLK WIRE BRN/VIO WIRE CENTRAL WINDOW REGULATOR SWITCH CLOSING ASSIST MOTOR COMFORT SYSTEM CENTRAL CONTROL MODULE (BEHIND GLOVE BOX) COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) CONVERTIBLE TOP OPERATION SWITCH DOOR CLOSING ASSIST CONTROL MODULE (AT TRUNK LID LATCH) FUSE 19 FUSE 32 FUSE PANEL GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL A FUSE 7 HOT AT ALL TIMES FUSE PANEL B FUSE 29 LEFT REAR DOOR CONTROL MODULE LEFT REAR WINDOW FRAME LOCK SENSOR (IN LEFT REAR WINDOW FRAME) LUGGAGE COVER CONTACT SWITCH ORG/BRN WIRE ORG/GRN WIRE PUSH BUTTON ILLUMINATION REAR WINDOW FRAME OPENING SENSOR (IN LEFT REAR WINDOW FRAME) RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR DOOR CONTROL MODULE SUNROOF BUTTON SUNROOF CIRCUIT BREAKER SUNROOF SWITCH/ CONVERTIBLE TOP OPERATION SWITCH VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE

BLK WIRE BLU WIRE BRN WIRE CENTRAL WINDOW REGULATOR SWITCH COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) DOOR LOCKS, MIRRORS SYSTEMS DRIVER WINDOW LOWERING MICROSWITCH DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR) DRIVER'S FRONT POWER WINDOWS SWITCH DRIVER'S REAR POWER WINDOWS SWITCH FRONT PASSENGER WINDOW LOWERING MICROSWITCH FUSE 12 FUSE 23 GRN WIRE GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL FUSE 32 LEFT FRONT WINDOW REGULATOR SWITCH LEFT REAR WINDOW REGULATOR SWITCH ORG/BRN WIRE ORG/GRN WIRE PASSENGER'S DOOR CONTROL MODULE (IN PASSENGER'S FRONT DOOR) RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR WINDOW SWITCH RIGHT FRONT WINDOW REGULATOR SWITCH RIGHT REAR WINDOW CONTROL MODULE (BEHIND RIGHT REAR SIDE PANEL) RIGHT REAR WINDOW REGULATOR SWITCH VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WINDOW MOTOR WINDOW MOTOR LEFT REAR WINDOW CONTROL MODULE (BEHIND LEFT REAR SIDE PANEL) YEL WIRE YEL/GRN WIRE YEL/GRY WIRE
