Volkswagen Eos I (2006-2011) brake pedal switch/front passenger's warning buzzer pedal switch wiring diagram
This page shows the only wiring diagram for the component.brake pedal switch/front passenger's warning buzzer pedal switch, which is found in the car Volkswagen Eos I (2006-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
brake pedal switch/front passenger's warning buzzer pedal switch wiring diagram (1 of 1)
BLU/GRY WIRE
BRAKE PEDAL SWITCH/FRONT PASSENGER'S WARNING BUZZER PEDAL SWITCH
BRN WIRE
BRN/WHT WIRE
CIGARETTE LIGHTER
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DRIVER'S DOOR CENTRAL WINDOW REGULATOR SWITCH
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR)
DRIVER'S FRONT WINDOW REGULATOR SWITCH
DRIVER'S INTERIOR LOCKING BUTTON
DRIVER'S REAR WINDOW REGULATOR SWITCH
DRIVING SCHOOL OPERATION RELAY
FOOTWELL ILLUMINATION SWITCH
FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S FRONT DOOR)
FRONT PASSENGER'S INTERIOR LOCKING BUTTON
GRN WIRE
GRY WIRE
GRY/WHT WIRE
LATE PRODUCTION EARLY PRODUCTION
ORG/BRN WIRE
ORG/GRN WIRE
OUTSIDE MIRROR SWITCH
POWER WINDOWS SYSTEM
REAR LID REMOTE CONTROL LOCK SWITCH/ FUEL TANK LID UNLOCK BUTTON
RED/BRN WIRE
RIGHT FRONT DOOR WINDOW REGULATOR SWITCH
SOCKET 2
W/ DRIVING SCHOOL EQUIPMENT
WARNING BUZZER SWITCH
Go to component -> Instrument illumination circuit (2 of 2) -> BRAKE PEDAL SWITCH/FRONT PASSENGER'S WARNING BUZZER PEDAL SWITCH
