Tire pressure monitoring circuit for Volkswagen Bora III (2012-2018)
Tire pressure monitoring circuit
ABS CONTROL MODULE
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 13
FUSE PANEL C
GRN WIRE
GRY WIRE
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
MULTI-FUNCTION INDICATOR
ORG/BLK WIRE
ORG/BRN WIRE
TIRE PRESSURE MONITORING DISPLAY BUTTON
TIRE PRESSURE MONITORING DISPLAY INDICATOR LAMP
W/O ESP W/ ESP
YEL WIRE
