Buzzer circuit, w/ low equipment for Volkswagen Bora III (2012-2018)
Buzzer circuit, w/ low equipment
AIR BAG CONTROL MODULE
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRAKE PAD WEAR IND LAMP
BRAKE SYSTEM INDICATOR LAMP
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DOOR AJAR IND LAMP
DRIVER DOOR CONTACT SWITCH
DRIVER DOOR LOCK UNIT
DRIVER SEAT BELT SWITCH
FRONT PASSENGER DOOR CONTACT SWITCH
FRONT PASSENGER DOOR LOCK UNIT
FRONT PASSENGER SEAT BELT SWITCH
FUSE 14
FUSE 3
FUSE PANEL C
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT FRONT BRAKE PAD WEAR SENSOR
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
PARKING BRAKE INDICATOR LAMP SWITCH
RED WIRE
SEAT BELT IND LAMP
SUPPLEMENTAL RESTRAINTS SYSTEM
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
WARNING BUZZER, TONE
YEL WIRE
