Trunk & fuel door release circuit, w/ low equipment for Volkswagen Bora III (2012-2018)
Trunk & fuel door release circuit, w/ low equipment
BLK/VIO WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DRIVER'S DOOR CONTROL MODULE
FUEL FILLER DOOR LOCK INDICATOR LAMP
FUEL FILLER DOOR UNLOCK MOTOR
FUSE 14
FUSE 45
FUSE 56
FUSE PANEL C
GRY WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LUGGAGE COMPARTMENT LAMP
ORG/BLK WIRE
ORG/BRN WIRE
REAR LID HANDLE RELEASE BUTTON
REAR LID LOCK UNIT
REAR LID LOCK/ ALARM CENTRAL LOCKING SWITCH
REAR LID OPENING MOTOR
REAR LID REMOTE RELEASE BUTTON, PUSH BUTTON ILLUMINATION BULB
RED/BLU WIRE
RED/YEL WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/WHT WIRE
VIO/YEL WIRE
YEL WIRE
