Supplemental restraints circuit for Volkswagen Bora III (2012-2018)

Supplemental restraints circuit (1 of 3)

Bora Volkswagen III (2012-2018): Supplemental restraints circuit (1 of 3)

Get access

AIR BAG CONTROL MODULE BLK WIRE BLK/RED WIRE BLU WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER HEAD CURTAIN AIR BAG IGNITER FRONT PASSENGER SEAT POSITION SENSOR FRONT PASSENGER'S AIR BAG DISABLED INDICATOR LAMP FRONT PASSENGER'S AIR BAG UNIT (UPPER RIGHT SIDE OF DASH) FRONT PASSENGER'S HEAD CURTAIN AIR BAG IGNITER FUSE 3 FUSE 9 FUSE PANEL C GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED IGNITER 1 IGNITER 2 NCA WIRE RED WIRE VIO WIRE WHT WIRE YEL WIRE YEL/BLU WIRE

Supplemental restraints circuit (2 of 3)

Bora Volkswagen III (2012-2018): Supplemental restraints circuit (2 of 3)

Get access

AIR BAG INDICATOR LAMP BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT BELT SWITCH DRIVER SEAT BELT TENSIONER IGNITER 1, DRIVER BELT FORCE LIMITER DRIVER SEAT POSITION SENSOR DRIVER THORAX AIR BAG IGNITER FRONT PASSENGER SEAT BELT SWITCH FRONT PASSENGER'S THORAX AIR BAG IGNITER GRN WIRE INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE NCA WIRE PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE PASSENGER OCCUPANT DETECTION SYSTEM PRESSURE SENSOR RED WIRE RED/WHT WIRE SEAT BELT INDICATOR LAMP VIO WIRE VIO/BLU WIRE WHT WIRE YEL WIRE YEL/BLU WIRE

Supplemental restraints circuit (3 of 3)

Bora Volkswagen III (2012-2018): Supplemental restraints circuit (3 of 3)

Get access

AIR BAG CONTROL MODULE AIR BAG SPIRAL SPRING/RETURN SPRING W/ SLIP RING BLK WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER AIR BAG IGNITER DRIVER FRONT AIR BAG CRASH SENSOR DRIVER SIDE AIR BAG CRASH SENSOR DRIVER SIDE REAR SIDE AIR BAG CRASH SENSOR FRONT PASSENGER SIDE AIR BAG CRASH SENSOR GRN WIRE GRY WIRE GRY/RED WIRE HYBRID BATTERY UNIT NCA WIRE ORG/BLK WIRE ORG/BRN WIRE PASSENGER FRONT AIR BAG CRASH SENSOR PASSENGER SIDE REAR SIDE AIR BAG CRASH SENSOR RED WIRE STEERING COLUMN ELECTRONICS CONTROL MODULE VIO WIRE WHT WIRE YEL WIRE YEL/BLU WIRE
