Power windows circuit, w/ low equipment for Volkswagen Bora III (2012-2018)
Power windows circuit, w/ low equipment
BLU WIRE
BLU/YEL WIRE
BRN WIRE
CHILD SAFETY LOCK BUTTON
CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
COMPUTER DATA LINES SYSTEM
DRIVER SIDE POWER WINDOW SWITCH
DRIVER'S DOOR CONTROL MODULE
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER DOOR WINDOW REGULATOR SWITCH, PUSH BUTTON ILLUMINATION BULB
FUSE 45
FUSE 46
FUSE PANEL C
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT WINDOW REGULATOR SWITCH
LEFT REAR DOOR CONTROL MODULE
LEFT REAR DOOR POWER WINDOW SWITCH, PUSH BUTTON ILLUMINATION BULB
LEFT REAR WINDOW REGULATOR SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
PUSH BUTTON ILLUMINATION BULB
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT POWER WINDOW SWITCH
RIGHT REAR DOOR CONTROL MODULE
RIGHT REAR DOOR WINDOW SWITCH, PUSH BUTTON ILLUMINATION BULB
RIGHT REAR WINDOW REGULATOR SWITCH
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WINDOW REGULATOR MOTOR
YEL WIRE
