Volkswagen Bora III (2012-2018) Navigation circuit, w/ amplifier

AMPLIFIER ANTENNA BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA 2 FM FREQUENCY FILTER (IN NEGATIVE WIRE) FM FREQUENCY FILTER (IN POSITIVE WIRE) GPS ANTENNA GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE LEFT "C" PILLAR) LEFT ANTENNA MODULE NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RADIO ANTENNA 2 RADIO/NAVIGATION DISPLAY UNIT CONTROL MODULE REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER RELAY RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RIGHT ANTENNA MODULE ROOF ANTENNA SATELLITE ANTENNA VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ HIGH EQUIPMENT W/ LOW EQUIPMENT WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE EXTERNAL AUDIO SOURCE CONNECTION FUSE 31 FUSE 57 FUSE PANEL B FUSE PANEL C GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES MULTIMEDIA SYSTEM CONTROL MODULE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE RADIO/NAVIGATION DISPLAY UNIT CONTROL MODULE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE SUBWOOFER W/ MULTIMEDIA INTERFACE W/O MULTIMEDIA INTERFACE WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE

BASS SPEAKER BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/YEL WIRE LEFT FRONT BASS SPEAKER/ LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR TREBLE SPEAKER MIDRANGE SPEAKER (+) NCA WIRE RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RIGHT FRONT BASS SPEAKER/ RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR TREBLE SPEAKER W/ HIGH EQUIPMENT W/ LOW EQUIPMENT WHT WIRE WHT/BLK WIRE
